Product Description

The DHU467 is a highly compact and ultra-lightweight 4K visible-light camera mounted on a 3-axis stabilized gimbal. Weighing approximately 110 grams, it is designed to offer stabilized imaging for small drones or handheld systems while minimizing power and payload demands.

⚙️ Key Features

• Sensor & Resolution: 1/2.8″ 8 MP CMOS sensor delivering 4K and 1080p video at 30 fps

• Zoom: Up to 7× digital zoom (no optical zoom)

• Video Output: Network streaming via RTSP, with onboard TF‑card recording capability

• Stabilization: 3-axis gimbal using high-precision encoder-based (FOC) control

• Control Interfaces: Network/IP, SBUS, UART, optional PWM

• Latency: Low-delay video stream (~170 ms)

• Autofocus: Real-time autofocus, under 1 second

• Power Input: DC 12–26 V; minimal power consumption, well-suited to light UAV systems

📏 Physical & Environmental Specs

• Dimensions: Approximately 120 mm × 68 mm

• Weight: Around 110 ± 10 grams

• Operating Temperature: –10 °C to +45 °C; humidity 20–80% RH

• Storage Conditions: –20 °C to +60 °C; up to 95% non-condensing RH

✅ Use Case

• Micro and lightweight UAV installations

• Portable inspection and surveillance platforms

• Situations requiring stabilized 4K imagery with minimal load and power draw

• Aerial scouting, mapping, or light reconnaissance missions
