Product Description

Roboguard is a wireless, battery-powered outdoor perimeter security system designed to deliver proactive early warning of intrusions. Each unit uses two passive infrared (PIR) sensors to project overlapping infrared beams in a 110° arc over a 20 m range—covering approximately 400 m². An alarm is only triggered when both beams are broken within 0.5 seconds, significantly reducing false alarms caused by animals, foliage, or wind.

The system’s HQ base station can monitor up to eight Roboguard sensors and receive alerts from up to 400 m away (or 800 m with a repeater). It features zone-specific indicators, tamper alerts, battery monitoring, panic-button control, and full integration with external sirens or alarm panels. Each sensor is powered by eight C-cell batteries lasting 3 to 5 years. The HQ has its own rechargeable battery, offering up to 50 hours of backup.

Ideal for residential, agricultural, and remote perimeter security, Roboguard is lightweight, relocatable, tamper-resistant, and fully weatherproof—making it a practical and reliable intrusion detection solution.

---

✅ Key Features

• Dual-Beam PIR Detection – Reduces false alarms by requiring simultaneous breach of both beams

• Wide Area Coverage – 20 m detection range with 110° field of view (≈400 m² per unit)

• Long-Range Wireless Communication – Sensor-to-base range up to 400 m (extendable to 800 m)

• Multi-Zone Monitoring – HQ supports up to 8 Roboguard sensors with zone-specific LEDs

• Battery Efficiency – Sensor batteries last 3–5 years; HQ offers 50-hour rechargeable backup

• Weatherproof & Tamper-Proof – Rugged casing resists UV, lightning, and intrusion

• Simple Installation – Wireless design enables easy setup without trenching or wiring

• Alarm System Integration – Connects to external sirens, panels, and panic-button systems

• Self-Diagnostics – Sensors send regular health status updates and tamper alerts

Roboguard provides trusted, low-maintenance protection to turn passive boundaries into active security zones—ideal for homes, farms, businesses, and remote installations.

Sensor Specific

Attribute	Value	Description	Why It Matters
Sensor Type	N/A	Vision / Force / Proximity / etc.	Detection capability
Detection Range	N/A	Minimum to maximum distance	Application requirements
Accuracy	N/A	Measurement precision	Application quality
Response Time	N/A	Signal processing delay	Real-time capability
Output Format	N/A	Analog / Digital / Network	Integration compatibility
Calibration	N/A	Calibration requirements	Maintenance needs
Environmental Rating	N/A	Operating conditions	Deployment environment
Power Consumption	N/A	Operating power requirements	System design impact

Form Factor

Attribute	Value	Description	Why It Matters
Height	10	Total standing height (cm)	Human-scale enables use of tools, navigation of spaces
Width	20	Shoulder-to-shoulder width (cm)	Affects balance, door/passage fit
Weight	52	Total mass (kg)	Impacts mobility, safety, power usage, transportability

Power System

Attribute	Value	Description	Why It Matters
Battery Type	Alkaline Battery	Li-ion / LiFePO4 / etc.	Determines energy density, safety
Battery Capacity		Wh or Ah	Impacts range and operating time
Operating Duration		Hours under normal load	Key for logistics, shift planning

Performance

Attribute	Value	Description	Why It Matters
Payload Capacity		Maximum carrying capacity (kg)	Determines real-world utility
Speed		Maximum operational speed	Task completion rate & productivity
Precision		Positioning accuracy (mm)	Quality of work & application suitability
Repeatability		Consistency of positioning (±mm)	Manufacturing quality & reliability
Cycle Time		Time per standard operation	Productivity & throughput calculations
MTBF		Mean Time Between Failures (hours)	Reliability & maintenance planning
Service Life		Expected operational lifespan (years)	ROI calculations & replacement planning

Connectivity

Attribute	Value	Description	Why It Matters
Communication Protocol		Wi-Fi / Ethernet / 5G / Bluetooth	Network integration capabilities
Remote Control		Web / App / Joystick / API	Needed for manual override or remote training
Programming Interface		Drag-drop / Code / Visual / Teach pendant	Ease of deployment and customization
Integration APIs		Available software interfaces	System integration capabilities
Cloud Connectivity		Cloud platform compatibility	Data analytics & remote monitoring
Security Features		Encryption & authentication methods	Cybersecurity compliance
