Orange Pi 5 is a powerful ARM-based SBC featuring an 8-core Rockchip RK3588S processor with GPU and NPU. It's compatible with Linux and Android and used in AI robotics, machine vision, and embedded Linux robots. Offers high performance for a fraction of Raspberry Pi 4's cost.
Product Description
The Orange Pi 5 (4GB) is a high-performance single-board computer powered by the Rockchip RK3588S processor, designed for developers, makers, and tech enthusiasts who demand powerful computing in a compact form. With 4GB of LPDDR4 RAM, this board offers a perfect balance of speed, efficiency, and versatility—ideal for advanced DIY projects, edge computing, AI development, and multimedia applications. With its robust hardware, broad I/O support, and flexible OS options, the Orange Pi 5 (4GB) stands out as a powerful and cost-effective alternative to traditional SBCs like Raspberry Pi. It’s especially suited for users who need enhanced performance for tasks like AI, high-resolution media processing, and multitasking without a large power footprint. Key Specifications:
- Processor: Rockchip RK3588S, 8-core (4x Cortex-A76 + 4x Cortex-A55), 64-bit
- GPU: ARM Mali-G610 MP4 – supports 8K video decoding and 4K encoding
- RAM: 4GB LPDDR4/4x (soldered onboard)
- Video Output: HDMI 2.1 (up to 8K @ 60Hz), MIPI DSI
- Camera Interfaces: 2x MIPI CSI
- Expansion: 26-pin GPIO header (Raspberry Pi-compatible)
- Other Interfaces: MIPI-CSI, MIPI-DSI, UART, SPI, I2C, PWM
- Power Supply: 5V/4A via USB-C
- Operating Systems Supported: Android 12, Ubuntu, Debian, and more (community-supported)
- website:
Controller Specific
| Attribute | Value | Description | Why It Matters |
|---|---|---|---|
| Processor Type | N/A | CPU architecture and speed | Computational capability |
| I/O Capacity | N/A | Digital/analog input/output count | System integration capacity |
| Memory | N/A | RAM and storage capacity | Program complexity capability |
| Real-time Capability | N/A | Deterministic response time | Motion control precision |
| Communication Interfaces | N/A | Network and fieldbus support | System connectivity |
| Programming Environment | N/A | Development software | Ease of implementation |
| Safety Features | N/A | Functional safety compliance | Human safety requirements |
| Expansion Options | N/A | Modular expansion capability | System scalability |
Form Factor
| Attribute | Value | Description | Why It Matters |
|---|---|---|---|
| Height | N/A | Total standing height (cm) | Human-scale enables use of tools, navigation of spaces |
| Width | N/A | Shoulder-to-shoulder width (cm) | Affects balance, door/passage fit |
| Weight | N/A | Total mass (kg) | Impacts mobility, safety, power usage, transportability |
Power System
| Attribute | Value | Description | Why It Matters |
|---|---|---|---|
| Battery Type | N/A | Li-ion / LiFePO4 / etc. | Determines energy density, safety |
| Battery Capacity | N/A | Wh or Ah | Impacts range and operating time |
| Operating Duration | N/A | Hours under normal load | Key for logistics, shift planning |
Performance
| Attribute | Value | Description | Why It Matters |
|---|---|---|---|
| Payload Capacity | N/A | Maximum carrying capacity (kg) | Determines real-world utility |
| Speed | N/A | Maximum operational speed | Task completion rate & productivity |
| Precision | N/A | Positioning accuracy (mm) | Quality of work & application suitability |
| Repeatability | N/A | Consistency of positioning (±mm) | Manufacturing quality & reliability |
| Cycle Time | N/A | Time per standard operation | Productivity & throughput calculations |
| MTBF | N/A | Mean Time Between Failures (hours) | Reliability & maintenance planning |
| Service Life | N/A | Expected operational lifespan (years) | ROI calculations & replacement planning |
Connectivity
| Attribute | Value | Description | Why It Matters |
|---|---|---|---|
| Communication Protocol | N/A | Wi-Fi / Ethernet / 5G / Bluetooth | Network integration capabilities |
| Remote Control | N/A | Web / App / Joystick / API | Needed for manual override or remote training |
| Programming Interface | N/A | Drag-drop / Code / Visual / Teach pendant | Ease of deployment and customization |
| Integration APIs | N/A | Available software interfaces | System integration capabilities |
| Cloud Connectivity | N/A | Cloud platform compatibility | Data analytics & remote monitoring |
| Security Features | N/A | Encryption & authentication methods | Cybersecurity compliance |
