Product Description

BeagleConnect Freedom is an open-source wireless platform designed for rapid IoT and IIoT prototyping. Built around the Texas Instruments CC1352P7 microcontroller, it supports both 2.4 GHz Bluetooth Low Energy and sub‑1 GHz long-range IEEE 802.15.4 communication standards.   Wireless & Processing Capabilities

• Powered by the TI CC1352P7 MCU: an Arm Cortex‑M4F running at 48 MHz, with 704 KB Flash, 256 KB ROM, 8 KB cache SRAM, and 144 KB low-leakage SRAM. It also supports over-the-air (OTA) updates.
• Fully open-source designs—including schematics, BOMs, and layouts—designed for long-term availability (10+ years) and robust community support.
• Leveraging the Zephyr RTOS, with full integration into Linux via kernel drivers, enabling true plug‑and‑play support for sensors, actuators, and indicators—no custom MCU coding required.
• Two mikroBUS™ sockets offer compatibility with over 1,000 Click add-on boards for diverse sensors, peripherals, and connectivity options.
• Integrated temperature, humidity, and light sensors
• USB‑C serial console and firmware programming via MSP430F5503
• 2 MB SPI flash, battery charger, buzzer, user-programmable LEDs and buttons
• JTAG connections for both main microcontroller and MSP430 for advanced debugging
• Supplied enclosure with a 2.4 GHz chip antenna and Sub-GHz U.FL connector
• Functions as both a node device (BLE & Sub‑GHz) or part of a larger BeagleConnect network with a BeaglePlay gateway. Supports up to 1 km low data-rate wireless reach.
• Ideal for sensor networks, building automation, remote monitoring, and similar applications

Controller Specific

Attribute	Value	Description	Why It Matters
Processor Type	N/A	CPU architecture and speed	Computational capability
I/O Capacity	N/A	Digital/analog input/output count	System integration capacity
Memory	N/A	RAM and storage capacity	Program complexity capability
Real-time Capability	N/A	Deterministic response time	Motion control precision
Communication Interfaces	N/A	Network and fieldbus support	System connectivity
Programming Environment	N/A	Development software	Ease of implementation
Safety Features	N/A	Functional safety compliance	Human safety requirements
Expansion Options	N/A	Modular expansion capability	System scalability

Form Factor

Attribute	Value	Description	Why It Matters
Height	10	Total standing height (cm)	Human-scale enables use of tools, navigation of spaces
Width	20	Shoulder-to-shoulder width (cm)	Affects balance, door/passage fit
Weight	52	Total mass (kg)	Impacts mobility, safety, power usage, transportability

Power System

Attribute	Value	Description	Why It Matters
Battery Type	Alkaline Battery	Li-ion / LiFePO4 / etc.	Determines energy density, safety
Battery Capacity		Wh or Ah	Impacts range and operating time
Operating Duration		Hours under normal load	Key for logistics, shift planning

Performance

Attribute	Value	Description	Why It Matters
Payload Capacity		Maximum carrying capacity (kg)	Determines real-world utility
Speed		Maximum operational speed	Task completion rate & productivity
Precision		Positioning accuracy (mm)	Quality of work & application suitability
Repeatability		Consistency of positioning (±mm)	Manufacturing quality & reliability
Cycle Time		Time per standard operation	Productivity & throughput calculations
MTBF		Mean Time Between Failures (hours)	Reliability & maintenance planning
Service Life		Expected operational lifespan (years)	ROI calculations & replacement planning

Connectivity

Attribute	Value	Description	Why It Matters
Communication Protocol		Wi-Fi / Ethernet / 5G / Bluetooth	Network integration capabilities
Remote Control		Web / App / Joystick / API	Needed for manual override or remote training
Programming Interface		Drag-drop / Code / Visual / Teach pendant	Ease of deployment and customization
Integration APIs		Available software interfaces	System integration capabilities
Cloud Connectivity		Cloud platform compatibility	Data analytics & remote monitoring
Security Features		Encryption & authentication methods	Cybersecurity compliance
